Pylontech US2000 48V 50Ah 2400Wh 15S2P LiFePO4 Battery 19" Rack Mount Metal Enclosure

US2000
Pylontech US2000 48V 50Ah 2400Wh 15S2P LiFePO4 Battery 19" Rack Mount Metal Enclosure

$1963 inc GST.

Our Best Price

Shipping & Handling Calculator:

Post Code:

Product Details

Model No	US2000
Selling Unit	EACH
Description	Pylontech US2000 48V 50Ah 2400Wh 15S2P LiFePO4 Battery 19" Rack Mount Metal Enclosure
Application	Home Power Storage, Telecommunications, Off Grid power, Industrial Power, Remote Infrastructure Power
Chemistry	Lithium Iron Phosphate (LiFePO4)
Voltage	48V
Nominal Capacity	50000mAh
Maximum Continuous Discharge Current	50000
Brand	Pylontech
Size	2RU
Width	442mm
Height	89mm
Length/Breadth/Depth	410mm
Weight	24000g
Brand	Pylontech

** Please call us for stock availability on this item on (02) 9534 5122 OR email us at [email protected] **

Important Information:

This Pylontech Battery can be connected in Unlimited Parallel configurations.

No Series connection allowed

External BMS

A LV-HUB communications hub is required when more than 1 string of batteries is paralleled.

A single LV-HUB communications hub can manage up to 5 strings of 8 batteries for a total of 40 US2000 batteries per LV-Hub

A total of five LV Hubs and their associated 40 batteries can then be parralled to a total 200 US2000 Batteries.

Systems containing between 2 to 5 LV Hubs will require 1 additional LV Hub to act as the Master Hub.

Communications:

RS232
RS485
CAN

Cabinets:

Click Here to view Cabinets & Accessories for this battery module

Pylontech US2000 48V 50Ah Rack Mounted LiFePO4 Battery Module

US2000 series is an ideal solution for residential storage applications, with standard 48V/50AH specification, up to 90% usable capacity and 6,000 cycle-life warranty.

Features:

Cycle life: >6000 cycles @ 25°C with 90% DoD for daily cyclic applications
Usable capcity of 2.16kWh @ 48 VDC
Working Temperature Range -10°C to 50°C, (Charging 0~50°C: Discharging -10~50°C)
Compact and fashionable 19" rack design to suit bracket, rack or cabinet installations
Modular design gives the you the power to design systems from 2.4kWh to a commercial sized 480kWh
Compatible with many available Hybrid inverters
Safety Cert.TüV, CE, R0HS, UN38, IEC62619, IEC62040, IEC61000-6-2, IEC61000-3
Communication Protocols: CAN, RS485, RS232
15+ Year Design Life
10 year Warranty
Clean Energy Council Approved (CEC)
