Pylontech US3000C 48V 74Ah 3552Wh 15S2P LiFePO4 Battery Rack Mount Metal Enclosure

US3000C
Pylontech US3000C 48V 74Ah 3552Wh 15S2P LiFePO4 Battery Rack Mount Metal Enclosure

$2486 inc GST.

Our Best Price

Shipping & Handling Calculator:

Post Code:

Product Details

Model No	US3000C
Selling Unit	EACH
Description	Pylontech US3000C 48V 74Ah 3552Wh 15S2P LiFePO4 Battery Rack Mount Metal Enclosure
Application	Home Power Storage, Telecommunications, Off Grid power, Industrial Power, Remote Infrastrucure Power
Chemistry	Lithium Iron Phosphate (LiFePO4)
Voltage	48V
Nominal Capacity	74000mAh
Maximum Continuous Discharge Current	74000
Brand	Pylontech
Size	3RU
Width	442mm
Height	132mm
Length/Breadth/Depth	420mm
Weight	32000g
Brand	Pylontech

** Please call us for stock availability on this item on (02) 9534 5122 OR email us at [email protected] **

Important Information:

Please check the Pylontech compatibilty guide to see if your inverter uses RS485 or Can Communication protocols.

When using RS485 protocol, This Pylontech Battery can be connected in up to 6 strings of 16 batteries for a total of 96 US3000C batteries in parallel. No LV Hub is required.

When using Can protocol,This Pylontech Battery can be connected in up to 6 strings of 16 batteries per LV Hub (6x16=96 Batteries per LV Hub), A total of 5 LV Hubs can then be paralleled up for a total of 480 US3000C batteries in parallel.(96x5=480 Batteries)

No Series connection allowed

External BMS

A LV-HUB communications hub is required when more than 1 string of batteries is paralleled using Can Communications Protocol.

A single LV-HUB communications hub can manage up to 6 strings of 16 batteries for a total of 96 US3000C batteries per LV-Hub

A total of five LV Hubs and their associated 96 batteries can then be parralled to a total 480 US3000C Batteries.

Systems containing between 2 to 5 LV Hubs will require 1 additional LV Hub to act as the Master Hub.

Communications:

RS232
RS485
CAN

Pylontech US3000C 48V 74Ah Rack Mounted LiFePO4 Battery Module

US3000C is the latest version HESS battery system designed by Pylontech. It's long life characteristics, highest energy and power density in the industry, fashionable design, easiness of installation and expansion, all reflect the real requirements of end users and the strong technical capability of Pylontech.

Pylontech ensure the highest quality by designing & manufacturing their own Lithium Phosphate (LiFePO4) batteries and BMS boards.

Features:

Cycle life: >6000 cycles @ 25°C with 95% DoD for daily cyclic applications
Usable capcity of 3.37kWh @ 48 VDC
Working Temperature Range -10°C to 50°C, (Charging 0~50°C: Discharging -10~50°C)
Compact and fashionable 19" rack design to suit bracket, rack or cabinet installations
Modular design gives the you the power to design systems from 3.5kWh to a commercial sized 1.704MWh
Compatible with many available Hybrid inverters
Backwards Compatible with existing US series products
Pre-charge function to pretect ESS from surge currents
Safety Cert. CE,TüV, UL, RoHS, UN38.3, IEC62619, IEC62040, IEC62477, IEC61000-6-2,IEC61000-3
Communication Protocols: CAN, RS485, RS232
15+ Year Design Life
10 year Warranty
Clean Energy Council Approved (CEC)
