The Motormate SDC series of chassis mountable compact DC-DC isolated power boosters / battery chargers use the latest switch mode technology providing in power supply mode a stable and clean power source with even voltage output over long cable distances. Additionally they are able to be used as a fully automatic battery charger suitable for all lead acid battery technologies
The SDC-1130A converts 10 ~ 16VDC to a selectable voltage of 13.2V, 13.5V or 13.8VDC of clean power with up to 90% efficiency. Series or parallel operation offer the flexibility to expand the power if required.
The converter can also be used as for battery charging to extend battery life. When in battery charging model it acts as a fully automatic charger with overcharge protection with selectable boost/absorbtion charge voltages @ 30amps of 14.2V, 14.6V or 14.8V that drops to 13.2V, 13.5V or 13.8V in a reduced current float charge mode. Also features a thermal control cooling fan with autostart and a 4 colour LED charge mode display
Other models are available within the SDC series with outputs suitable for 12VDC or 24VDC.
Also includes external remote on/off switching.
Featuring a tough anodized aluminium case with mounting cover and a wide range operating temperature, overload and short circuit protection with LED indication.
Click the datasheet link below for full information and specifications.
